Processore zapco dspz8iii

Descrizione

vendo processore Zapco dsp-z8iii ...usato ma in buone condizioni 6 canali ingressi bilanciati RCA 2 Canali RCA Ingressi ausiliari Accetta da 0,5 a 26 Volt TosLink SPDIF Ingresso Ottico Cirrus Logic CS4271 DAC DSP ST Micro STA308A Audio Uscita 8 canali a 6 volt RMS Ingresso livelli altoparlanti fino a 26 volt RMS Canale Summing per combinare la gamma del segnale attivo con un singolo segnale full range THD+Noise <0.1% Signal to Noise >96dB Channel Separation >68dB Signal to Noise Ratio > 90dB Signal Delay Resolution 0.01ms Phase Control: 15° Steps 0~180 Frequency Response 15Hz to 30KHz ±1dB Input Sensitivity .25v to 5v Preamp Output 3.5V RMS Voltage Sensitive EQ Band/Ch to correct factory active Equalization Adjustment by channel or by channel pair 10 bands parametric equalization for each Channel Choose a frequency or type in your own Adjustable Q 0.5 to 10 • ± 15dB adjustment each band Digital Electronic Crossover for each output channel HP/LP/BP/Full Range selectable 6dB to 36dB/Octave slopes Butterworth or Linkwitz / Riley design Time Delay for each output channel to .01mm or =3mm Voltage sensitive EQ band lets you compensate for OEM equalized systems Phase control in steps at 0°, 45°, 90°, and 180° Muting by Channel or Channel pair Isolate the channel you are working with and turn the rest off Dimensioni: 120 x 41 x 200 mm
